The PWE-4803RU is an 802.3af compliant Power over Ethernet (PoE) power source designed to support PoE powered devices. Standards-based Power over Ethernet affords a one-wire solution for connecting Ethernet devices, delivering power and data over a single CAT5/6 network cable. Using the PWE-4803RU, there is no need to install a separate power supply at the device location. The PWE-4803RU can simply be mounted at any convenient location up to 100 meters (328 feet) from the device.
Output Rating
350 mA maximum @ 48 Volts DC nominal;
IEEE 802.3af Class 0 PoE Power Sourcing Equipment
Connectors
LAN (1) 8-wire RJ45, female;
10BaseT/100BaseTX Ethernet port;
Connects to Ethernet LAN
LAN PoE (1) 8-wire RJ45, female;
10BaseT/100BaseTX Ethernet pass-thru port and IEEE 802.3af Class 0 PoE Power Sourcing Equipment output
Main Power Input (1) IEC 320 C14 socket;
Mates with removable power cord, included
Dimensions
Height 1.35 in (3.43 cm)
Width 2.40 in (6.10 cm)
Depth 3.98 in (10.11 cm)
Power Requirements
100-250 Volts AC, 50/60 Hz
LED Indicators
POWER (1) Tri-color LED;
Amber indicates power is available but no device is connected;
Green indicates a PoE device is connected and drawing power;
Red (flashing) indicates a non-PoE device is connected
