Powersoft Amplifiers Ottocanali 8K4 DSP+D
Overview
The Ottocanali 8K4 DSP+D is a flexible and reliable 8-channel power amplifier with up to a total of 8,000 W at 4Ω, ideal for multi-zone applications in medium to large-scale installs: Ottocanali 8K4 DSP+D supports any combination of lo-Z loudspeakers, mono-bridgeable channel pairs and 70V/100V Hi-Z distributed lines with no need for output step-up transformers. The Ottocanali 8K4 DSP+D features switchable main/aux signal inputs and offers a wide range of system control, alarms, GPI/O, and monitoring functions as well as sound shaping options.
The Ottocanali 8K4 DSP+D implements universal switch mode power supplies with PFC and patented SRM (Smart Rails Management) technology maximizing reliability & efficiency and reducing power consumption.
New Ottocanali 8K4 DSP+D heralds new and innovative levels of signal processing. Providing flexible routing and mixing, multi-stage equalization with raised-cosine, IIR, and FIR filters, delay up to 2 s in input processing and 100 ms for time alignment, gain and polarity adjustment, crossover, peak limiters, TruePower™ limiters, and Active DampingControl™.
Powersoft’s legendary efficiency saves valuable energy, keeping operational cost and ‘carbon footprint’ at a minimum: the Ottocanali 8K4 DSP+D shines with outstandingly low power consumption and heat dissipation. This dramatically reduces costs from the AC mains supply and air conditioning/cooling systems – not to mention the environmental benefits for a greener planet.
MyPowersoft services are available for this product.
Features
Power supply
- Universal switch mode power supply up to 400VAC tolerant with Power Factor Correction
- Patented output filter with ripple cancellation network
- Low Inrush Limiting reduces AC inrush current, removing the need for expensive power sequencers
- Detachable AC mains cable with IEC C19/22.2 (16A for EU, 20 A for USA) socket
Protections
Fully protected circuit design with:
- Ac protection: shut down power supply when AC mains voltage is outside the operating range
- Clip limiter: prevents severely clipped waveforms from reaching loudspeakers, while still maintaining full peak power output
- DC protection: protects against infrasonic signal at the outputs
- VHF protections: protects the loudspeakers against nonaudible, strong, nonmusical high-frequency signals
- Short circuit protection: protects the amplifier from short circuit or other stressful events for the output circuits with automatic protection reset
- Long-term limiter: protects the loudspeaker against steady long-term RMS (nonaudio) signals, by reducing the maximum output
- Thermal protection: output stages operating temperature up to 80 °C (176 °F)
- Temperature-controlled continuous variable speed fan, front-to-back airflow
General
- Fixed frequency switch mode output stage for high-grade sound accuracy
- All models 2 RU for reduced rack cost and space
- Lightweight – for easier racking and shipping: 14 kg / 30.8 lbs
- Standard Phoenix connectors: analog and digital input, audio outputs, aux supply, alarms and GPIO
- Remotely switchable double input
Loudspeaker system configuration
- Direct drive either low impedance loads or 70V / 100V Hi-Z distributed lines
- Switchable 35Hz / 70Hz high pass filter per channel
- Mixed configuration with Lo-Z/Hi-Z systems possible
- Bridged mode, with low impedance, per channel pair
Digital Signal Processing
- TI C6000 DSP platform architecture
- AD/DA converter: dual 24bit @ 96 kHz Tandem® architecture, 127 dB dynamic range, per channel
- Input/output independent equalizers per channel providing Raised-cosine, custom FIR, parametric IIR: peaking, hi/lo-shelving, all-pass, band-pass, band-stop, hi/lo-pass
- Crossovers: linear phase (FIR), hybrid (FIR-IIR), Butterworth, Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
- Input delay up to 2s and output delay up to 100ms for time alignment per channel
- Active DampingControl™ for cable compensation
- Power limiter (TruePower™, RMS voltage, RMS current) + Peak Limiter
Alarms and GPIO
- NC/NO contacts per channel for alarm notifications
- Remote ON/OFF switch
- Remote AUX/MAIN inputs switch
- PWS OUT connector providing 24VDC
Remote management
- Control and monitoring through ArmoníaPlus
Specifications
| GENERAL | |||
| Output power per Channel | |||
| Output power per Channel | 850 W @ 2 Ω | 1000 W @ 4 Ω | 600 W @ 8 Ω |
| Bridge mode | 1700 W @ 4 Ω | 2000 W @ 8 Ω | |
| Max output voltage / current | |||
| Single channel mode | 90 Vpeak / 23 Apeak | ||
| AC MAIN POWER | |||
| Power supply | Universal, regulated switch mode witd PFC (Power Factor Correction) | ||
| Nominal power requirement | 100-240 V ±10%, 50-60 Hz | ||
| Operating voltage | 90 V – 264 V | ||
| Power consumption/current draw | |||
| Idle | 115 V: 74 W – 0.85 A | 230 V: 77 W – 0.75 A | |
| 1/8 of max output power @ 4 Ω | 115 V: 1425 W – 12.6 A | 230 V: 1425 W – 6.6 A | |
| THERMAL | |||
| Operating temperature range | 0° – 35° C – 32° – 95° F | ||
| Thermal dissipation* | |||
| Idle | 115 V: 253 BTU/h – 64 kcal/h | 230 V: 263 BTU/h – 66 kcal/h | |
| 1/8 of max output power @ 4 Ω | 115 V: 1480 BTU/h – 373.0 kcal/h | 230 V: 1504 BTU/h – 379.0 kcal/h | |
| 1/4 of max output power @ 4 Ω | 115 V: 2792 BTU/h – 703.6 kcal/h | 230 V: 2722 BTU/h – 685.9 kcal/h | |
