Vanguard Audio Labs VLSM Large Shockmount

SKU: VLSM shockmount

Large shockmount with aerospace-grade suspension rings

Quantity:

About this item

Product

Description

The Vanguard Audio Labs VLSM Large Shockmount is a heavy-duty, professional-grade shock mount designed to give your mics long-lasting, high-grade support.

Re-Imagined Design

Let’s face it – it was high time to rethink the standard “spider-style” shock mount of yore. We have an open front to the VLSM, which allows you to position your microphone as close to the source as possible while preventing early reflections from the front at 120 degrees.

We also wanted to get rid of the aggravating experiences with those flimsy elastic bands that come standard with most shock mounts. They get stretched out and saggy, and sometimes snap without warning – not something you want to happen when your mic is in there! Instead, we install aerospace-grade rubberized suspension rings that won’t break, sag, crack, or stretch over time. We picked a precise durometer for the suspension rings that will firmly support even the heaviest microphones, while still maintaining superb decoupling properties to prevent unwanted rumble and vibration.

Wide Compatability

The VLSM comes as a standard accessory for the Vanguard V13 Tube Condenser and V44S Stereo Condenser microphones. However, it utilizes a standard M22x1 ISO Metric threading. The VLSM should be compatible with up to 68mm (2.68″) diameter microphones with M22 threading at their base.

Features

Construction

We use heavy-duty zinc and aluminum alloys during the construction of the VLSM. There are no brazes or welds that can weaken over time. Instead, each component is precision-cast & machined. We chose to make the swivel out of impact-resistant ABS thermoplastic polymer to provide superior friction for the mounting swivel. This will keep the microphone from slowly sliding out of position.

Features

  • Heavy-duty brass & zinc metal construction
  • Aerospace-grade suspension rings
  • Open-faced design
  • M22 threading for wide compatibility with microphones from other brands

Specs

  • Outside Diameter: 117mm (≈4 5/8″)
  • Inside Diameter: 70mm (≈2 5/8″)
  • Height: 109mm (≈4 3/8″)
  • Open-face arc: 120°
  • Knurled Locking Collar Threading: M22x1
